VME Extender Cards    Type C, F and H15 Power


C96 F48 F24/H7 H15 Accessories
extc.JPG (26038 bytes) extf.JPG (26334 bytes) extfh.JPG (24817 bytes) exth.JPG (90296 bytes) extfhc.jpg (9046 bytes)

For VME and Eurocard Signal and Power



FKN extender cards for VME and other Eurocard applications provide a right angle male and female connector at each end to bring the circuit paths of a PCB with a standard DIN connector out of the card cage for trouble shooting and development. Card guide ejector latches on the front end can be used as handles and to eject the board from the card cage. Some cards are available with clip-on test point loops for attaching cables.



Just Need DIN Connectors  Go to  www.2esyscom.com



C Series 96 Pin Extender Card


Part# C-2000-C96- Standard 96 pin C series signal connectors at each end of this extender card bring the circuit paths from inside the card cage to the female connector on the outside. 96 clip-on test loops are available for trouble shooting and product development. Cards are available with and without ejector handles and card guides.

Call for more information.



F Series 48  Pin Extender Card


Part# C-2000-F48- The F series extender card provides 48 circuit paths from the male connector on the card cage side to the outside female connector. Each circuit trace has contacts attached for clipping on test cab les. Cards are xyz inches long. Cards are supplied with or without ejector latches. Heavy duty ejector latches can be used for holding cards with power supplies mounted.







F24/H7 Extender Card


Part# C-2000-F24/H7- The mixed pin F24/H7 extender card provides 7 H15 contacts and 24 F type contacts. Built in clip on test loops allow attachment of cable for for trouble shooting and development. Mix and match H,F,C and F24/H series cards for 6U or 9U card cages by using the aluminum mating channels. Standard or heavy duty card guides/ejector handles can be attached as desired.







H15 Extender Card


Part# C-2000-H15 -01- The H15 extender card provides a right angle male and female connector at each end to bring the circuit paths of a 15 Amp per pin H15 connector out of the card cage for trouble shooting and development. Ejector latches on the front end can be used as handles and to eject the board from the card cage. Traces can carry 15 A/Path. The extender card length is 28cm.



Accessories


1. Card Guides and Heavy Duty Card Guides with ejector handles act as lead in and hold in guides for cards to be brought out from the card cage.

2. Mating channel can be used to mount several cards side by side for 6U and 9U applications.

Standard Card Guide: PN: 00 - 1002VC

Heavy Duty Card Guide: PN: 00 - 1003VC

Mating Channel: PN: 00 - 1001VM

Call for more information.
